Thermal Circuit Breakers, Reset Overload Breaker Button 5-40A 250 Terminal Multicolor(25a)

Product DescriptionMechanical/Environmental DataOperating Ambient Temperature: -10 to +60Mounting: Various options. See Ordering Information and drawingsTermination: 250''(6.35mm)quick connects or solder terminalsApprovalRated current Rated voltage350A 125250VAC; 50VDC007 3-30A 125/250VAC; 32VDC3-30A 125/250VAC.3-16A 125/250VAC3-30A 125VACMechanical/Environmental DataOperating Ambient Temperature: -10 to +60Mounting: Various options. See Ordering Information and drawingsTermination: 250''(6.35mm)quick connects or solder terminalsCurrent rating range5~30AInput voltage rating:125/250VAC; 32/50VDCInterrupting Capacity125/250VAC; 32/50VDCTypical life1,000 operations at 200% overload1,000 operations at 200% overloadInsulation co-orationRated impulse withstand voltage 2.5kV Rated impulse withstand voltage 2.5kVDielectric Strength>1.500VAC/min.Insulation Resistance>100MOHM (DC 500V)Degree of protectionTerminal area IP00, operating area IP40Calibration(at25)100 % of Rated Current: Hold , No Trip300% of Rated Current: 1.5-5.0 sec Trip200% of Rated Current: 5-30 sec Trip 150% ofRated Current: Trip Within 1 Hour==========Type : Moulded CaseModel Number : 98-25AIs Smarts Device : NoOrigin : Mainland ChinaModel Number : 98-25AType : OtherPoles Number : OtherRated Voltage : 250V/125VACRated Frequency : 50/60hzInput Power : 125VAC/250VAC/32VDC 50-60HzColor Button : Black/White/Red/BlueRating : 3A-50AWithstand voltage : 1500VAC/1minReset : Manual ResetCertificate : CUL/VDE/CQC/SAA/IECProduct name :98 15A button reset overload protector circuit breakerColor Houseing : Black

• APPLICATION:Circuit overload protectors switch can play the role of over current protection and short circuit protection, protecting the power circuit from overheating due to overload.
• FEATURE:and wear-resistant, ensuring long service life, reliable use.
• Good insulation, heat resistance, melting resistance and good conductivity, which can maintain stable current connection and excellent thermal sensor.
• CIRCUIT PROTECTION: Compact design enables high density circuit protection configuration. Made of durable plastic, and long service life.
• Widely used in mechanical and electrical systems, this overload protector helps forestall overload risks in air compressors and other equipment, offering immediate For response to faults.
